For decades, Klipsch has ruled the professional cinema space with
exceptional sounding, high output cinema speakers designed and built
at our factory in Hope, Arkansas. Now the same components used in
those speakers all over the world can now bring movie night home.
Utilizing the same acoustic and network components as our legendary
professional cinema speakers, the all-new Real Custom Cinema systems
are specifically designed to bring exceptional performance and
power of these professional speakers to the home theater.
The modular false-wall design allows for incredibly easy system design
and installation, while eliminating light creep from behind the screen
for a professional cinema experience - acoustically and visually.
Introducing the Real Custom Cinema Series from Klipsch. High
performance, professional-grade cinema speakers for the home.
Proudly designed, engineered, and built-in Hope, Arkansas, USA.

• An ultra-premium, high-performance behind-the-screen LCR/Sub
• system for 112”-121” wide screens
• 18” high output poly-fiber cinema subwoofer drivers
• 15” high output poly-fiber cinema woofers
• 3” titanium HF cinema compression drivers
• 90° x 60° Tractrix® Horns
• The modular design ensures a full coverage, easy installation, with no
• light creep
• Premium double-braced MDF construction with high impact
• textured black finish



SPECIFICATIONS :

• SPEAKER SYSTEM : Behind-The Screen LCR/SUB System for Screens 112”-121” in Width
• MAX CONTINUOUS OUTPUT : 126 dB
• MAX PEAK OUTPUT : 132 dB
• SYSTEM FREQUENCY RESPONSE : 18 - 20kHz
• POWER HANDLING : LCRs (Each) : 200W Continuous, 800W Peak, SUBS (Each) : 600W Continous, 2400W Peak
• SYSTEM SENSITIVITY : 107 dB, 2.83V @ 1m, 1/2 space
• HORIZONTAL COVERAGE : 90° +/- 20 (1.1kHz - 20kHz)
• VERTICAL COVERAGE : 60° +/- 20 (2.2kHz - 20kHz)
• NOMINAL IMPEDENCE : 8 Ohm
• MINIMUM RECOMMENDED
• AMPLIFIER POWER : LCRs : 200W RMS, SUBs : 500W RMS
• HIGH-FREQUENCY DRIVERS : (3) K-702 1.75” Titanium Compression Driver Mounted on a K-603-M Horn
• LOW-FREQUENCY DRIVERS : (3) K-45-ST 15” Polyfiber Woofers
• SUBWOOFER DRIVERS : (2) K-49-EP 18” Polyfiber Woofers
• ENCLOSURE TYPE : Double Braced Dado and Rabbit MDF
• INPUTS : Dual 5-Way Binding Posts
• SYSTEM HEIGHT : 55” (139.7 cm)
• SYSTEM WIDTH : 101.25” (257.18 cm)
• SYSTEM DEPTH : 20.25” (51.44 cm)
• SYSTEM WEIGHT : 648 lbs (293.93 kg)
• FINISH : Textured Black Paint
• RECOMMENDED SCREEN WIDTH : 102” - 112”
• RECOMMENDED SCREEN SIZE
• (DIAGONAL) : 16:9: 117” - 129”, 1:2.35: 110” - 121”
